Siemens QJ23B200 Circuit Breaker, 200A, 240V, 3Pole (New In Box)

UPC: not available

Siemens QJ23B200 Circuit Breaker, 200A, 240V, 3Pole (New In Box)

Description Designed for commercial use, this 200A Siemens MCCB delivers reliable thermal-magnetic protection. The QJ-frame device features a non-interchangeable trip unit. This unit mount breaker integrates seamlessly into Siemens P1, P2, and P3 panelboards, along with compatible switchboards. For future upgrades, it is replaced by the QR23B200. Operating at 240VAC with a 10kAIC rating, the three-pole breaker includes load side lugs. It is HACR rated and supports reverse feed applications. Specifications Key specifications Brand Siemens Part Number QJ23B200-R Series QJ Amperage 200A Poles 3 Mounting Style Unit Mount Voltage 240VAC Phase 3 AIC Rating 10kA @ 240VAC Fit and installation Terminal Type Lugs For Use With Siemens P1, P2, P3 Panelboards, Switchboards, Meter Centers Wire Gauge 6 AWG - 300 kcmil (Cu), 4 AWG - 300 kcmil (Al) Max Wire 300 kcmil Min Wire 6 AWG (Cu), 4 AWG (Al) Protection and operation Trip Technology Thermal Magnetic Trip Function Code LI Trip Function Long-Time, Instantaneous Trip Adjustability Fixed Thermal, Fixed Magnetic Standards and features Available Options Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release Accessories Load Side Lugs Standards CSA C22.2 No. 5, UL 489 Approval CSA, UL Temp Rating 40C Construction Features HACR Rated, Reverse Feed, Non-Interchangeable Trip, Quick-Make/Quick-Break, Trip-Free Mechanism
